Models YTF-63 and YTF-100
Dual Scales in PSI and BAR Standard
63 mm (2 1 /2 ") and 100 mm (4") Diameters
Back or Lower Mount Fittings
All Stainless Steel Pressure Gauges
Liquid Fillable in the Field
IP65 Protection

The YWKM-1A high-frequency dynamic pressure transmitter is made by utilizing the extremely high Young's modulus of elasticity and excellent mechanical properties of semiconductor silicon, allowing the sensor to have a high natural frequency. Combined with our company's advanced internal and external structural design, it reduces frequency loss. Thus obtaining a high response frequency and rise time, it is an ideal product for measuring high-frequency dynamic pressure.

The YW-150 diaphragm pressure transmitter adopts internationally advanced diffusion silicon sensor core, combined with high-precision electronic components, and is strictly assembled through laser resistance adjustment and temperature compensation, linear compensation, signal amplification, V/I conversion, pressure overload current limiting and other process processes. It has passed long-term aging and stability assessment. It has functions such as resistance to overvoltage, overcurrent, reverse, lightning strikes, and electromagnetic interference. Suitable for liquid level measurement of open solutions, and for all other industrial applications such as gas and liquid pressure automation measurement and control in the fields of petroleum, chemical, coal mine, power, water conservancy, medicine, food, light textile, etc.

The YW-3051DP intelligent differential pressure transmitter is suitable for liquid, gas differential pressure or flow measurement.

The XYM-3051 pressure transmitter is a high-performance monocrystalline silicon pressure transmitter carefully developed using highly stable monocrystalline silicon pressure transmitter technology and temperature compensation technology. This product adopts a central overload protection diaphragm design and an internal circuit surge protection design, which can accurately measure gauge pressure, absolute pressure, flow rate, vacuum degree, liquid level, and density.

The YW-130G pressure transmitter is composed of an oil filled pressure sensor with an isolation film and an instrument specific integrated amplifier circuit, which makes it characterized by high accuracy, good stability, long service life, high reliability, and easy installation.

485 communication digital pressure gauge can be connected to a network of 255 units, monitoring the pressure value, and configuring upper computer software is convenient and practical

The YW-130 piezoresistive pressure transmitter uses a piezoresistive OEM pressure sensor with stainless steel isolation film as the signal measurement element, and has undergone computer automatic testing. The zero point and temperature performance compensation for a wide temperature range have been achieved using laser resistance adjustment technology. The signal processing circuit is located inside a stainless steel housing and converts the sensor signal into a standard output signal. The entire product has undergone strict testing and aging screening of components, semi-finished products, and finished products, with stable and reliable performance. This product is widely used for pressure measurement and control in industrial processes such as petroleum, chemical, metallurgy, power, hydrology, etc. due to its excellent reliability, flexibility, and diversity.

The YW-140 pressure transmitter adopts a high stability sensor and integrated junction box design with high-performance computer laser resistance adjustment for temperature compensation. Equipped with dedicated wiring terminals and digital display, it is easy to install, calibrate, and maintain. This series of products is suitable for various enterprises and institutions such as petroleum, water conservancy, chemical engineering, metallurgy, power, light industry, scientific research, environmental protection, etc., to measure fluid pressure and be suitable for all weather environments and various corrosive fluids in various occasions.

Rosemount 3051 pressure transmitters have set industry standards for pressure measurement. This transmitter can be used to measure differential, absolute, or gage pressure. These pressure transmitters help improve production and operational efficiencies in various process industries. Equipped with Power Advisory Diagnostics and a Local Operator Interface (LOI), these pressure transmitters enable easy installation and help reduce commissioning times. They are designed to withstand tough environments in the process industries.

Model 3051 double flange liquid level transmitter is a new type of transmitter produced by our company with the introduction of foreign advanced technology and equipment. The key raw materials, components and parts of the double flange liquid level transmitter are imported from abroad. Strictly assembled and tested, the double flange liquid level transmitter has the characteristics of advanced design principles, complete varieties and specifications, and easy installation and use.

Clean the flat type isolation diaphragm, which complies with the international 3A health standard;
Range: 0-5KPa~35MPa;
Power supply: 15-36VDC

Suitable MediumLiquid, gasUnsuitable MediasolidThis product is widely used in water plants, oil refineries, sewage treatment plants, building materials, light industry, machinery and other industrial fields to realize the measurement of liquid, gas, and vapor pressure.

This product is widely used in water plants, oil refineries, sewage treatment plants, building materials, light industry, machinery and other industrial fields to realize the measurement of liquid, gas, and vapor pressure.

The display pressure sensor uses diffused silicon core as sensitive element. The internal ASIC converts the sensor millivolt signal into a standard voltage, current or frequency signal, which can be directly connected to the computer interface card, control instrument, intelligent instrument or PLC. current output mode can be used for distance transmission. It is small, light weight, all stainless steel sealing structure, can work in a co-corrosion environment. The product is easy to install and has high vibration and impact resistance.

diffusion silicon 4~20mA small differential pressure/pressure/liquid level injection can replace petrochemical,
metallurgy, electric power, food and medicine, papermaking, and textile industries. It is used to detect fluid differential
pressure, pressure, liquid level, density and other parameters, and is tested The signal is converted into 4~20mA.DC and sent to
display, calculation, adjustment or control instruments, which can form various automatic control systems.
